DC 10~24V Touchless Infrared Sensor Button, Stainless Steel
- Form C relay output (1A@30VDC)
- Adjustable output time 0.5~20 sec. Trigger / Toggle
- Adjustable sensing range 3~15cm
- Voltage : 10V/24V DC (auto-adjusting)
- The front of the detector is waterproof design.
Dimension: Unit(mm)
Example Applications
-
Elevator Buttons
-
Parking Lot Ticket Machine
-
Water Dispensers
-
Ticket Machine
-
Device Switch
-
Hospital Door/Operating Room Automation Control
-
Anti-theft Detection
-
Automatic Location Detection
-
Gate/Door/Exit/Automation Control
RELATED PRODUCTS
Model：PBT-22IRV
IR Proximity Sensor, ø22mm, Polycarbonate
*Form C relay output (1A@30VDC)
*Adjustable output time 0.5~20 sec. Trigger / Toggle
*Adjustable sensing range 0.5~10cm/3-15cm
*Voltage : 10V/24V DC (auto-adjusting)
*Front panel IP65 weatherproof for outdoor use
Model：PBT-09IRAV
DC 10~24V Touchless Infrared Sensor Button
*Form C relay output (1A@30VDC)
* Adjustable output time 0.5~20 sec. Trigger / Toggle
*Adjustable sensing range 3~15cm
*10V/24V DC (auto-adjusting)
*The front of the detector is waterproof design.
Model：PBT-07IRAV
DC 10~24V Touchless Infrared Sensor Button
*Form C relay output (1A@30VDC)
*Adjustable output time 0.5~20 sec. Trigger / Toggle
*Adjustable sensing range 3~15cm
*Voltage : 10V/24V DC (auto-adjusting)
*The front of the detector is waterproof design.
Model：PBT-09IRAE
DC 10~24V Touchless Infrared Sensor Button
*Form C relay output (1A@30VDC)
*Adjustable output time 1~12 sec.
*Adjustable sensing range 4~15cm
*Voltage : 10V/24V DC (auto-adjusting)
*The front of the detector is waterproof design.
Model：PBT-09IRAC
DC/AC 10~24V Touchless Infrared Sensor Button
*Form C relay output (1A@30VDC)
*Adjustable output time 0.5~20 sec. Trigger / Toggle
*Adjustable sensing range 3~15cm
*Voltage : 10/24V DC/AC(auto-adjusting)
*The front of the detector is waterproof design.
Model：PBT-211IRBV
DC 10~24V Touchless Infrared Sensor Button, Stainless Steel
*Form C relay output (1A@30VDC)
*Adjustable output time 0.5~20 sec. Trigger / Toggle
*Adjustable sensing range 3~15cm
*Voltage : 10V/24V DC (auto-adjusting)
*The front of the detector is waterproof design.
Model：PBT-186IRC
Flush-Mount Touchless Infrared Sensor Button
*Form C relay output (1A@30VDC)
*Adjustable output time 1~15 sec. Trigger / Toggle
*Adjustable sensing range 1.5~10cm
*Voltage : 10V/24V DC/AC (auto-adjusting)
