Model:PBT-211IRBV

DC 10~24V Touchless Infrared Sensor Button, Stainless Steel

  • Form C relay output (1A@30VDC)
  • Adjustable output time 0.5~20 sec. Trigger / Toggle
  • Adjustable sensing range 3~15cm
  • Voltage : 10V/24V DC (auto-adjusting)
  • The front of the detector is waterproof design.
compare Compare Inquiry (0)
Certification
Product



Dimension: Unit(mm)

Example Applications

  • Elevator Buttons

  • Parking Lot Ticket Machine

  • Water Dispensers

  • Ticket Machine

  • Device Switch

  • Hospital Door/Operating Room Automation Control

  • Anti-theft Detection

  • Automatic Location Detection

  • Gate/Door/Exit/Automation Control

Specification
Dimension(mm)
Touchless Infrared Sensor Button, Stainless Steel
Hole distance
84mm
Voltage / Current
DC10V (42mA)~24V(26mA)
Relay type
Form C dry contact, N.O./N.C./COM., 1A@30VDC, 0.3A@60VDC, 0.5A@125VAC
Output time
0.5~20 sec, Trigger / Toggle
Sensor Range
3~15cm
LED Status indicator
Power on: Red, Proximity: Blue (Optional Blue/Green)
Case material
IR Sensor: UV & Fire Polycarbonate / Face Plate: Stainless Steel
IP Rating
IP65 (IR Sensor)
Operating life
Relay: 100,000 cycles
Download
※ The specifications listed are subject to change by the company. If they differ from the actual product, the actual product shall prevail.
