30MM Mini Flush-Mount RFID Reader
- Mini Flush-Mount RFID reader
- Support 125KHz(EM / H.I.D.) & 13.56MHz(Mifare / DESFire / FeliCa / ICODE-2(Optional))
Application field
 |
 |
 |
 |
| Access control system | Mailbox management system | Intercom system | Lift access control system |
 |
 |
 |
 |
| Charging station | HMI、PLC | Production control | Vehicle rental system |
 |
 |
 |
|
| Kiosk/POS System | Membership System | Library automation |
Dimension: Unit(mm)
How to assembly
RELATED PRODUCTS
Model：PQ-510
QR code & RFID reader
● Dual-Function Design: Combines QR Code scanning and RFID reading in one device, supporting 125KHz and 13.56MHz frequencies.
● High Compatibility: Supports popular RFID card formats such as EM, H.I.D., Mifare, Felica, NFC Ntag213/215/216.
● Barcode Versatility: Compatible with both 2D QR Code and 1D Barcode formats.
● Easy Installation: Wall-mounted design with multiple connection interfaces, including RS-232, RS-485, and USB, for seamless system integration.
● Flexible Applications: Generates access-authorized QR Codes (one-time or time-sensitive) via Pegasus software, usable through mobile photos, email, or direct printing.
Model：PP-22
22MM Mini Flush-Mount RFID reader
● Mini Design: Adopts a high protection level, can be embedded into space-limited access control devices, saving space while providing efficient identity recognition.
● Supported Frequencies: 13.56 MHz; compatible with MIFARE® Classic, Plus, Ultralight, DESFire, NFC Ntag213/215/216, ISO14443 B (optional), and ICODE-2 (optional).
● Easy Installation: Only requires drilling a 22MM diameter hole for installation. Easy to install with IP68 waterproof and dustproof rating.
● Wide Application: Suitable for access control, elevator floor management, production line HMI equipment, intercom systems, and various other scenarios.
● Operating Voltage Range: DC7~28V, compatible with most power supplies on the market.
