HOME Product AC/DC IR Proximity Sensor, ø22mm, Polycarbonate

SHARE

Model：PBT-22IRC

AC/DC IR Proximity Sensor, ø22mm, Polycarbonate

Form C relay output (1A@30VDC)
Adjustable output time 0.5~20 sec. Trigger / Toggle
Adjustable sensing range 0.5~10cm/3-15cm
Voltage : 10V/24V DC/AC (auto-adjusting)
Front panel IP65 weatherproof for outdoor use

Compare Inquiry (0)

Certification

AC/DC IR Proximity Sensor, ø22mm, Polycarbonate

Product
Specification
Download

Product

Dimension: Unit(mm)

Example Applications

Elevator Buttons
Parking Lot Ticket Machine
Water Dispensers

Ticket Machine
Device Switch
Hospital Door/Operating Room Automation Control

Anti-theft Detection
Automatic Location Detection
Gate/Door/Exit/Automation Control

Ordering information

PBT-22IRC	DC/AC10~24V Touchless Infrared Sensor Switch, Adjustable proximity range: 3~15cm
PBT-22IRSC	DC/AC10~24V Touchless Infrared Sensor Switch, Adjustable proximity range: 0.5~10cm

Specification

Dimension(mm)

28.6(L)x28.6(W)x38(D)

Voltage / Current

DC10V (45mA)~24V(26mA) / AC10V (74mA)~24V(51mA)

Relay type

Form C dry contact, N.O./N.C./COM. 1A@30VDC, 0.3A@125VAC

Output time

0.5~20 sec, Trigger / Toggle

Sensor Range

3~15cm

LED Status indicator

Power on: Red, Proximity: Blue (Optional Blue/Green)

Case material

UV & Fire Polycarbonate

IP Rating

IP65

Operating life

Relay: 100,000 cycles

Download

Selection Guides For Infrared Sensor Switch Series

Download

※ The specifications listed are subject to change by the company. If they differ from the actual product, the actual product shall prevail.
